Spectral Imager

Spectral Imager Technology and Fundamentals of Spectral Imaging

A spectral imager is an optical measurement system that not only captures light as an image but also simultaneously analyzes its spectral properties. This creates a dataset that combines spatial information with spectral signatures. This combination enables significantly more precise analysis of materials and surfaces. While conventional cameras only capture intensities in the visible spectrum, a spectral imager processes light in many individual wavelength ranges.

The basis of this technology lies in the decomposition of light into its spectrum. Optical components such as diffraction gratings or prisms separate the incident radiation into defined wavelength ranges. Sensors then capture the intensity of each spectral channel. This results in detailed spectral profiles. On the one hand, material properties can be identified; on the other hand, chemical compositions can be analyzed. Another advantage lies in the high information density. A spectral imager generates so-called spectral data cubes. These datasets combine image coordinates with spectral information. This creates a multidimensional analytical foundation for research and industry, for example in systems such as the Rox Reflectance Box.

Splitting Light into Spectral Wavelengths

A spectral imager operates on the principle of spectral decomposition of light. First, reflected or emitted radiation strikes the sensor’s optical system. This radiation contains many different wavelengths. Optical elements such as prisms or diffraction gratings separate the incident light into individual spectral ranges. This results in a detailed spectrum of the captured signal. The decomposition is highly precise. Each wavelength range is captured separately, allowing for the detection of subtle differences in reflection behavior.

This enables the differentiation of materials with similar appearances and also reveals chemical properties. A spectral imager utilizes this capability by simultaneously analyzing the light spatially and spectrally. Following the spectral decomposition, the actual data acquisition takes place. Sensor arrays register the intensity of the individual wavelengths. The measured values are then digitally processed. This creates a so-called spectral data cube. This data set combines image information with spectral signatures and forms the basis of advanced optical measurement solutions developed by JB Hyperspectral.
